Item # JMS 230
AM Machinery 23' Hydraulic Grapple Loader
Hydraulic Grapple loaders are popular options for road trailers. They can easily manipulate logs and other objects with great precision. All grapples have a 360 boom rotation and hydraulic telescopic stabilizers. Grapple loaders come attached to log trailers if they are ordered together. You can also purchase the grapple loader separately and attach it to the carrier of your choice. Grapples and rotators are available separately also.
Boom Length 23'
Boom Rotation 360
GPM 6
Max Grapple Opening 56"
Min. Grapple Opening 4"
Grapple Rotation Continuous
Rack & Pinion Double
Half Boom Capacity 3500 lbs
Maximum Reach 3000 lbs
Working Pressure 3000 PSI
Stabilizers Telescopic
Mounting Bolted
Boom Rotation 360
GPM 6
Max Grapple Opening 56"
Min. Grapple Opening 4"
Grapple Rotation Continuous
Rack & Pinion Double
Half Boom Capacity 3500 lbs
Maximum Reach 3000 lbs
Working Pressure 3000 PSI
Stabilizers Telescopic
Mounting Bolted
Specs
Boom Length 23'
Boom Rotation 360
GPM 6
Max Grapple Opening 56"
Min. Grapple Opening 4"
Grapple Rotation Continuous
Rack & Pinion Double
Half Boom Capacity 3500 lbs
Maximum Reach 3000 lbs
Working Pressure 3000 PSI
Stabilizers Telescopic
Mounting Bolted
Boom Rotation 360
GPM 6
Max Grapple Opening 56"
Min. Grapple Opening 4"
Grapple Rotation Continuous
Rack & Pinion Double
Half Boom Capacity 3500 lbs
Maximum Reach 3000 lbs
Working Pressure 3000 PSI
Stabilizers Telescopic
Mounting Bolted
